LEVEL THREE

THE MAKER’S PACKAGE

The whole story—from the beautiful exterior to what holds it all together.

The Maker’s Package is our most comprehensive design and engineering service.

This level includes the detailed information required to understand how the project is constructed, estimate materials, coordinate fabrication, and communicate the design to the people responsible for building or installing it.

The exact contents of the package will be tailored to the project and its construction requirements.

This package may include:

• Complete dimensional drawing set

• Multiple elevations and detailed views

• Individual component and part dimensions

• Material thicknesses and specifications

• Joinery and fastening details

• Section views

• Exploded views where appropriate

• Hardware specifications

• Construction and fabrication notes

• Material quantity estimates

• Lumber requirements or bill of materials

• Assembly details

• Installation and coordination information

• Final fabrication drawing package delivered as a PDF

Best suited for:

Projects being prepared for fabrication, installation, contractor coordination, material purchasing, or production by Ross Alan Design or another qualified fabricator.

Important note:

The Maker’s Package provides a detailed design and fabrication roadmap. Architectural, structural, mechanical, electrical, plumbing, permit, or stamped engineering drawings are not included unless specifically identified within the proposal.

Design Investment: Starting at $1,650
